ENGLISH
Opening/Closing the
sliding door
Preparation
Press [Í] to turn the unit on.
For disc operations:
A While the sliding door is closed, press [CD
<]
to open the sliding door.
For iPod/iPhone operations:
B While the sliding door is closed, press [iPod
<]
to open the sliding door.
∫ Closing the sliding door
Press [CD <] or [iPod <] again.
≥ Keep fingers away from the sliding door when it is closing to avoid possible
minor injuries.
≥ Damage may occur if the sliding door is forced closed.
≥ Be careful of CD hitting the sliding door while being removed.
≥ The sliding door will not close if the docking switch lever is not returned to the
original position.
With this function the sliding door can be opened without
pressing a button. The sliding door will open or close by moving
the palm of your hand over the sensors on the top of the unit.
For disc operations:
Place the palm of your hand over sensor B and
then move it over sensor A.
≥ To close the sliding door, place the palm of your hand over
sensor A and then move it over sensor B.
For iPod/iPhone operations:
Place the palm of your hand over sensor A and
then move it over sensor B.
≥ To close the sliding door, place the palm of your hand over
sensor B and then move it over sensor A.
∫ To change the setting of the open/close sensor
The sensitivity of the sensor can be changed to increase or
decrease the activating area of the open/close sensor.
Press [OPEN/CLOSE SENSOR] repeatedly to
select “MODE 1”, “MODE 2”, “MODE 3” or
“OFF SENSOR”.
Select the mode that allows correct operation.
≥ Factory preset: “MODE 2”
≥ To turn the open/close sensor off, select “OFF SENSOR”.
∫ To change the sound effect settings of the
open/close sensor
1 Press [SOUND] repeatedly to select “BUZZER”.
2 Press [
2] or [1] to select the following setting.
≥ A red light is lit from the position of the sensor. This is normal.
≥ The open/close sensor might be unintentionally activated if an object, hand,
part of your arm, pets or children move over the top of the unit.
≥ If the open/close sensor does not react, move the palm of your hand closer to
the top of the unit and change the speed that you move your hand.
≥ If the open/close sensor does not work, try changing the sensor’s setting. If it
still does not work, open/close the sliding door using the buttons on the unit or
the remote control.
≥ When the sensor setting is changed to “MODE 1”, move your hand closer
(approx. 3 cm (1
1
/
8
')) over the unit.
≥ The disc operation side of the sliding door will not open during CD playback
or pause.
Disc operations
1
Press [Í] to turn the unit on.
2
Open the sliding door. (> left)
3
With the label of the disc facing
towards you, tilt the disc into the
disc tray under the sliding door.
4
Place the disc onto the spindle in
the center and then push the disc
down until it clicks into place.
≥ Make sure that the unit does not fall when
inserting the disc.
5
Close the sliding door. (> left)
Hc V770 Manual
∫ Removing a disc
1 Open the sliding door.
2 Hold the center and the top right of the disc and pull the top
right of the disc to unlock it from the spindle.
3 Tilt the disc so as not to touch the sliding door or the lens and
remove the disc.
Opening the sliding door
[HC55]
Open/Close sensor
A
B
ンモュリヰ
ヷヰロヶヮユ
ヷヰロヶヮユ
LOW:
Set the sound effect level to low.
MID:
Set the sound effect level to medium.
HIGH:
Set the sound effect level to high.
OFF:
Turn the sound effect off.
Inserting a disc
SC-HC55_35-RQTX1260.book 9 ページ ２０１１年４月４日 月曜日 午後４時５０分
[HC55]
THE FOLLOWING APPLIES ONLY IN THE U.S.A.
FCC Note:
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses,
and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio
communications.
However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
≥ Reorient or relocate the receiving antenna.
≥ Increase the separation between the equipment and receiver.
≥ Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
≥ Consult the dealer or an experienced radio/TV technician for help.
FCC caution: To maintain compliance with FCC regulations, shielded
interface cables must be used with this equipment. Operation with non-
approved equipment or unshielded cables may result in interference to
radio and TV reception. Any changes or modifications not approved by the
party responsible for compliance could void the user’s authority to operate
this equipment.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including
interference that may cause undesired operation.
Responsible Party:
Panasonic Corporation of North America
One Panasonic Way
Secaucus, NJ 07094
Support Contact:
Panasonic Consumer Electronics Company
Telephone No.: 1-800-211-PANA (7262)
Panasonic Sc Hc 35 Manual
WARNING:
To satisfy FCC RF exposure requirements for mobile transmitting devices, a
separation distance of 20 cm (7
7
/
8
q) or more should be maintained between
the antenna of this device and persons during device operation. To ensure
compliance, operations at closer than this distance is not recommended.
The antenna used for this transmitter must not be co-located in conjunction
with any other antenna or transmitter.
[HC35]
THE FOLLOWING APPLIES ONLY IN THE U.S.A.
FCC Note:
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
≥ Reorient or relocate the receiving antenna.
≥ Increase the separation between the equipment and receiver.
≥ Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
≥ Consult the dealer or an experienced radio/TV technician for help.
Any unauthorized changes or modifications to this equipment would void
the user’s authority to operate this device.
This device complies with Part 15 of the FCC Rules. Operation is subject to
the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Responsible Party:
Panasonic Corporation of North America
One Panasonic Way
Secaucus, NJ 07094
Support Contact:
Panasonic Consumer Electronics Company
Telephone No.: 1-800-211-PANA (7262)
Panasonic Sc-hc35 User Manual
For SC-HC55 only
As an ENERGY
STAR
Partner,
Panasonic has
determined that this product meets the ENERGY
STAR
guidelines for energy efficiency.
®
®
For Canada only: The word 'Participant' is used
in place of the word 'Partner'.
For U.S.A. and Puerto Rico
Panasonic Consumer Electronics Company,
Division of Panasonic Corporation of North America
One Panasonic Way, Secaucus,
New Jersey 07094
http://www.panasonic.com
C Panasonic Corporation 2011
Printed in Malaysia
For Canada
Panasonic Canada Inc.
5770 Ambler Drive
Mississauga, Ontario
L4W 2T3
www.panasonic.ca
